R7F100GAG2DSP#AA0微控制器Renesas

發布時間：2024-07-15 09:26:59     瀏覽：241

　　R7F100GAG2DSP#AA0是Renesas公司推出的RL78/G23微控制器系列中的一員。這款微控制器以其超低功耗和豐富的功能而著稱，適用于多種應用場景。


　　主要特點：

　　1. 超低功耗：

　　工作電流為41μA/MHz，確保在運行時的高效能耗比。

　　在停止模式下，數據保留電流僅為210nA，適用于4KB的SRAM，這使得該微控制器在間歇操作時功耗極低。

　　2. 寬工作電壓范圍：

　　支持1.6V至5.5V的寬電壓范圍，適應多種電源環境。

　　最高工作頻率可達32MHz，滿足高速處理需求。

　　3. 大容量存儲：

　　內置高達768KB的代碼閃存和48KB的RAM，提供充足的存儲空間。

　　4. 多功能集成：

　　集成了電容式觸摸傳感單元(CTSU2L)，支持觸摸感應應用。

　　包含邏輯和事件鏈路控制器(ELCL)，增強系統的事件處理能力。

　　5. 靈活的封裝選項：

　　提供從30引腳到128引腳的多種封裝選項，滿足不同設計需求。

　　6. 豐富的開發環境：

　　提供快速原型開發板，支持用戶通過易于使用的GUI進行編程和調試。

　　只需連接USB電纜和智能配置器，無需額外工具，簡化開發流程。

　　7. 兼容性：

　　與現有的RL78系列兼容，可以無縫替代，方便升級和維護。

　　應用領域：

　　R7F100GAG2DSP#AA0微控制器適用于廣泛的領域，包括家用電器、消費電子產品和工業設備等，特別適合對功耗有嚴格要求的應用場景。

型號：

Product ID程序存儲器 （KB）內存 （KB）溫度范圍模數轉換器數模轉換器產品尺寸 （mm）
R7F100GAG2DSP#AA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAG3CSP#AA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAJ2DSP#AA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAJ3CSP#AA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GBG2DFP#AA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBG2DNP#AA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBG3CFP#AA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBG3CNP#AA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ2DFP#AA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBJ3CFP#AA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GEG2DNP#AA012816-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEG3CNP#AA012816-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GFG2DFP#AA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFG3CFP#AA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFJ2DFP#AA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFJ3CFP#AA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFL2DFP#AA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFL3CFP#AA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFN2DFP#AA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFN3CFP#AA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GGG2DFB#AA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGG2DNP#AA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGG3CFB#AA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGG3CNP#AA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ2DFB#AA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGJ3CFB#AA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGL2DFB#AA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGL3CFB#AA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGN2DFB#AA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGN3CFB#AA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GJG2DFA#AA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJG3CFA#AA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJJ2DFA#AA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJJ3CFA#AA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJL2DFA#AA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJL3CFA#AA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJN2DFA#AA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJN3CFA#AA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLG2DFB#AA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLG3CFB#AA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLJ2DFB#AA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLJ3CFB#AA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLL2DFB#AA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLL3CFB#AA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLN2DFB#AA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLN3CFB#AA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GMJ2DFB#AA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMJ3CFB#AA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GML2DFB#AA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GML3CFB#AA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMN2DFB#AA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMN3CFB#AA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GPL2DFB#AA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPL3CFB#AA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPN3CFB#AA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GSL2DFB#AA051248-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSL3CFB#AA051248-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSN2DFB#AA076848-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSN3CFB#AA076848-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GAF2DSP#AA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAF2DSP#BA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAF2DSP#HA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAF3CSP#AA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAF3CSP#BA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAF3CSP#HA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAG2DSP#BA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAG2DSP#HA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAG3CSP#BA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAG3CSP#HA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAH2DSP#AA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAH2DSP#BA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAH2DSP#HA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAH3CSP#AA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAH3CSP#BA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAH3CSP#HA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAJ2DSP#BA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAJ2DSP#HA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAJ3CSP#BA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GAJ3CSP#HA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch10 x 6 x 1.4
R7F100GBF2DFP#AA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBF2DFP#BA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBF2DFP#HA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBF2DNP#AA09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBF2DNP#BA09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBF2DNP#HA09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBF3CFP#AA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBF3CFP#BA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBF3CFP#HA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBF3CNP#AA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBF3CNP#BA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBF3CNP#HA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBG2DFP#BA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBG2DFP#HA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBG2DNP#BA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBG2DNP#HA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBG3CFP#BA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBG3CFP#HA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBG3CNP#BA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBG3CNP#HA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBH2DFP#AA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBH2DFP#BA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBH2DFP#HA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBH3CFP#AA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBH3CFP#BA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBH3CFP#HA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBJ2DFP#BA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBJ2DFP#HA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBJ3CFP#BA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GBJ3CFP#HA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GEF2DNP#AA09612-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEF2DNP#BA09612-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEF2DNP#HA09612-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEF3CNP#AA09612-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEF3CNP#BA09612-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEF3CNP#HA09612-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEG2DNP#BA012816-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEG2DNP#HA012816-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEG3CNP#BA012816-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEG3CNP#HA012816-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GFF2DFP#AA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFF2DFP#BA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFF2DFP#HA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFF3CFP#AA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFF3CFP#BA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFF3CFP#HA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFG2DFP#BA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFG2DFP#HA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFG3CFP#BA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFG3CFP#HA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFH2DFP#AA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFH2DFP#BA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFH2DFP#HA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFH3CFP#AA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFH3CFP#BA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFH3CFP#HA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFJ2DFP#BA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFJ2DFP#HA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFJ3CFP#BA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFJ3CFP#HA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFK2DFP#AA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFK2DFP#BA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFK2DFP#HA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFK3CFP#AA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFK3CFP#BA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFK3CFP#HA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFL2DFP#BA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFL2DFP#HA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFL3CFP#BA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFL3CFP#HA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFN2DFP#BA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFN2DFP#HA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFN3CFP#BA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GFN3CFP#HA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch10 x 10 x 1.6
R7F100GGF2DFB#AA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGF2DFB#BA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGF2DFB#HA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGF2DNP#AA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGF2DNP#BA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGF2DNP#HA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGF3CFB#AA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGF3CFB#BA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGF3CFB#HA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGF3CNP#AA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGF3CNP#BA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGF3CNP#HA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGG2DFB#BA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGG2DFB#HA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGG2DNP#BA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGG2DNP#HA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGG3CFB#BA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGG3CFB#HA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGG3CNP#BA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGG3CNP#HA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGH2DFB#AA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGH2DFB#BA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGH2DFB#HA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGH3CFB#AA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGH3CFB#BA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGH3CFB#HA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGJ2DFB#BA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGJ2DFB#HA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGJ3CFB#BA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGJ3CFB#HA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGK2DFB#AA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGK2DFB#BA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGK2DFB#HA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGK3CFB#AA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGK3CFB#BA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGK3CFB#HA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGL2DFB#BA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGL2DFB#HA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGL3CFB#BA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGL3CFB#HA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGN2DFB#BA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGN2DFB#HA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGN3CFB#BA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GGN3CFB#HA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 1.7
R7F100GJF2DFA#AA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJF2DFA#BA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJF2DFA#HA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJF3CFA#AA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJF3CFA#BA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJF3CFA#HA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJG2DFA#BA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJG2DFA#HA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJG3CFA#BA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJG3CFA#HA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJH2DFA#AA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJH2DFA#BA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJH2DFA#HA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJH3CFA#AA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJH3CFA#BA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJH3CFA#HA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJJ2DFA#BA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJJ2DFA#HA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJJ3CFA#BA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJJ3CFA#HA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJK2DFA#AA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJK2DFA#BA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJK2DFA#HA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJK3CFA#AA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJK3CFA#BA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJK3CFA#HA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJL2DFA#BA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJL2DFA#HA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJL3CFA#BA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJL3CFA#HA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJN2DFA#BA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJN2DFA#HA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJN3CFA#BA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GJN3CFA#HA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLF2DFA#AA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLF2DFA#BA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLF2DFA#HA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLF2DFB#AA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLF2DFB#BA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLF2DFB#HA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLF3CFA#AA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLF3CFA#BA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLF3CFA#HA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLF3CFB#AA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLF3CFB#BA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLF3CFB#HA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLG2DFA#AA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLG2DFA#BA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLG2DFA#HA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLG2DFB#BA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLG2DFB#HA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLG3CFA#AA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLG3CFA#BA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLG3CFA#HA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLG3CFB#BA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLG3CFB#HA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLH2DFA#AA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLH2DFA#BA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLH2DFA#HA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLH2DFB#AA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLH2DFB#BA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLH2DFB#HA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLH3CFA#AA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLH3CFA#BA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLH3CFA#HA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLH3CFB#AA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLH3CFB#BA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLH3CFB#HA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLJ2DFA#AA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLJ2DFA#BA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLJ2DFA#HA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLJ2DFB#BA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLJ2DFB#HA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLJ3CFA#AA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLJ3CFA#BA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLJ3CFA#HA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLJ3CFB#BA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLJ3CFB#HA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLK2DFA#AA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLK2DFA#BA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLK2DFA#HA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLK2DFB#AA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLK2DFB#BA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLK2DFB#HA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLK3CFA#AA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLK3CFA#BA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLK3CFA#HA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLK3CFB#AA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLK3CFB#BA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLK3CFB#HA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLL2DFA#AA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLL2DFA#BA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLL2DFA#HA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLL2DFB#BA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLL2DFB#HA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLL3CFA#AA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLL3CFA#BA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLL3CFA#HA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLL3CFB#BA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLL3CFB#HA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLN2DFA#AA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLN2DFA#BA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLN2DFA#HA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLN2DFB#BA076848-40 to 85°C12-bit x 26-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLN2DFB#HA076848-40 to 85°C12-bit x 26-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLN3CFA#AA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLN3CFA#BA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLN3CFA#HA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch12 x 12 x 1.6
R7F100GLN3CFB#BA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GLN3CFB#HA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch10 x 10 x 1.7
R7F100GMG2DFA#AA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMG2DFA#BA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMG2DFA#HA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMG2DFB#AA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMG2DFB#BA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMG2DFB#HA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMG3CFA#AA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMG3CFA#BA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMG3CFA#HA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMG3CFB#AA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMG3CFB#BA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMG3CFB#HA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMH2DFA#AA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMH2DFA#BA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMH2DFA#HA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMH2DFB#AA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMH2DFB#BA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMH2DFB#HA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMH3CFA#AA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMH3CFA#BA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMH3CFA#HA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMH3CFB#AA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMH3CFB#BA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMH3CFB#HA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMJ2DFA#AA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMJ2DFA#BA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMJ2DFA#HA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMJ2DFB#BA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMJ2DFB#HA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMJ3CFA#AA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMJ3CFA#BA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMJ3CFA#HA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMJ3CFB#BA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMJ3CFB#HA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMK2DFA#AA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMK2DFA#BA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMK2DFA#HA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMK2DFB#AA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMK2DFB#BA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMK2DFB#HA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMK3CFA#AA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMK3CFA#BA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMK3CFA#HA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMK3CFB#AA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMK3CFB#BA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMK3CFB#HA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GML2DFA#AA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GML2DFA#BA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GML2DFA#HA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GML2DFB#BA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GML2DFB#HA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GML3CFA#AA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GML3CFA#BA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GML3CFA#HA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GML3CFB#BA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GML3CFB#HA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMN2DFA#AA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMN2DFA#BA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMN2DFA#HA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMN2DFB#BA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMN2DFB#HA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMN3CFA#AA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMN3CFA#BA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMN3CFA#HA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GMN3CFB#BA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GMN3CFB#HA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch12 x 12 x 1.7
R7F100GPG2DFA#AA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPG2DFA#BA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPG2DFA#HA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPG2DFB#AA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPG2DFB#BA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPG2DFB#HA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPG3CFA#AA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPG3CFA#BA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPG3CFA#HA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPG3CFB#AA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPG3CFB#BA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPG3CFB#HA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPH2DFA#AA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPH2DFA#BA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPH2DFA#HA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPH2DFB#AA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPH2DFB#BA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPH2DFB#HA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPH3CFA#AA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPH3CFA#BA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPH3CFA#HA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPH3CFB#AA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPH3CFB#BA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPH3CFB#HA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPJ2DFA#AA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPJ2DFA#BA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPJ2DFA#HA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPJ2DFB#AA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPJ2DFB#BA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPJ2DFB#HA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPJ3CFA#AA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPJ3CFA#BA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPJ3CFA#HA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPJ3CFB#AA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPJ3CFB#BA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPJ3CFB#HA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPK2DFA#AA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPK2DFA#BA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPK2DFA#HA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPK2DFB#AA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPK2DFB#BA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPK2DFB#HA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPK3CFA#AA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPK3CFA#BA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPK3CFA#HA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPK3CFB#AA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPK3CFB#BA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPK3CFB#HA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPL2DFA#AA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPL2DFA#BA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPL2DFA#HA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPL2DFB#BA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPL2DFB#HA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPL3CFA#AA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPL3CFA#BA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPL3CFA#HA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPL3CFB#BA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPL3CFB#HA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPN2DFA#AA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPN2DFA#BA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPN2DFA#HA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPN2DFB#AA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPN2DFB#BA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPN2DFB#HA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPN3CFA#AA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPN3CFA#BA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPN3CFA#HA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GPN3CFB#BA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GPN3CFB#HA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch14 x 14 x 1.7
R7F100GSJ2DFB#AA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSJ2DFB#BA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSJ2DFB#HA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSJ3CFB#AA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSJ3CFB#BA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSJ3CFB#HA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSK2DFB#AA038432-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSK2DFB#BA038432-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSK2DFB#HA038432-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSK3CFB#AA038432-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSK3CFB#BA038432-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSK3CFB#HA038432-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSL2DFB#BA051248-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSL2DFB#HA051248-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSL3CFB#BA051248-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSL3CFB#HA051248-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSN2DFB#BA076848-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSN2DFB#HA076848-40 to 85°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSN3CFB#BA076848-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GSN3CFB#HA076848-40 to 105°C12-bit x 26-ch8-bit x 2-ch20 x 14 x 1.6
R7F100GBH2DNP#AA019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBH2DNP#BA019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBH2DNP#HA019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBH3CNP#AA019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBH3CNP#BA019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBH3CNP#HA019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ2DNP#AA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ2DNP#BA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ2DNP#HA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ3CNP#AA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ3CNP#BA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GBJ3CNP#HA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch5 x 5 x 0.8
R7F100GEH2DNP#AA019220-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEH2DNP#BA019220-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEH2DNP#HA019220-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEH3CNP#AA019220-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEH3CNP#BA019220-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEH3CNP#HA019220-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEJ2DNP#AA025624-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEJ2DNP#BA025624-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEJ2DNP#HA025624-40 to 85°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEJ3CNP#AA025624-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEJ3CNP#BA025624-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GEJ3CNP#HA025624-40 to 105°C12-bit x 9-ch8-bit x 2-ch6 x 6 x 0.8
R7F100GGH2DNP#AA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGH2DNP#BA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGH2DNP#HA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGH3CNP#AA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGH3CNP#BA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGH3CNP#HA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ2DNP#AA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ2DNP#BA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ2DNP#HA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ3CNP#AA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ3CNP#BA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGJ3CNP#HA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGK2DNP#AA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGK2DNP#BA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGK2DNP#HA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGK3CNP#AA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGK3CNP#BA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGK3CNP#HA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGL2DNP#AA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGL2DNP#BA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGL2DNP#HA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGL3CNP#AA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGL3CNP#BA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGL3CNP#HA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGN2DNP#AA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGN2DNP#BA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGN2DNP#HA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGN3CNP#AA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGN3CNP#BA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GGN3CNP#HA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch7 x 7 x 0.8
R7F100GCF2DLA#AC09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCF2DLA#BC09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCF2DLA#HC09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCF3CLA#AC09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCF3CLA#BC09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCF3CLA#HC09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCG2DLA#BC012816-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCG2DLA#HC012816-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCG2DLA#AC012816-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCG3CLA#AC012816-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCG3CLA#BC012816-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCG3CLA#HC012816-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCH2DLA#AC019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCH2DLA#BC019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCH2DLA#HC019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCH3CLA#AC019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCH3CLA#BC019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCH3CLA#HC019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCJ2DLA#AC025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCJ2DLA#BC025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCJ2DLA#HC025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCJ3CLA#HC025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCJ3CLA#AC025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GCJ3CLA#BC025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch4 x 4 x 0.76
R7F100GLN2DLA#AC076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLN2DLA#BC076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLN2DLA#HC076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLN3CLA#AC076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLN3CLA#BC076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLN3CLA#HC076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLL2DLA#AC051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLL2DLA#BC051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLL2DLA#HC051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLL3CLA#AC051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLL3CLA#BC051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLL3CLA#HC051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLK2DLA#AC038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLK2DLA#BC038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLK2DLA#HC038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLK3CLA#AC038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLK3CLA#BC038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLK3CLA#HC038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLJ2DLA#AC025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLJ2DLA#BC025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLJ2DLA#HC025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLJ3CLA#AC025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLJ3CLA#BC025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLJ3CLA#HC025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLH2DLA#AC019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLH2DLA#BC019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLH2DLA#HC019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLH3CLA#AC019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLH3CLA#BC019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLH3CLA#HC019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLG2DLA#AC012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLG2DLA#BC012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLG2DLA#HC012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLG3CLA#AC012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLG3CLA#BC012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLG3CLA#HC012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLF2DLA#AC09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLF2DLA#BC09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLF2DLA#HC09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLF3CLA#AC09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLF3CLA#BC09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLF3CLA#HC09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch5 x 5 x 0.76
R7F100GLN2DAA#AC076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN2DAA#BC076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN2DAA#HC076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN3CAA#AC076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN3CAA#BC076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN3CAA#HC076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL2DAA#AC051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL2DAA#BC051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL2DAA#HC051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL3CAA#AC051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL3CAA#BC051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL3CAA#HC051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK2DAA#AC038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK2DAA#BC038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK2DAA#HC038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK3CAA#AC038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK3CAA#BC038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK3CAA#HC038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ2DAA#AC025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ2DAA#BC025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ2DAA#HC025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ3CAA#AC025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ3CAA#BC025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ3CAA#HC025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH2DAA#AC019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH2DAA#BC019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH2DAA#HC019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH3CAA#AC019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH3CAA#BC019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH3CAA#HC019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG2DAA#AC012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG2DAA#BC012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG2DAA#HC012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG3CAA#AC012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG3CAA#BC012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG3CAA#HC012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF2DAA#AC09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF2DAA#BC09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF2DAA#HC09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF3CAA#AC09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF3CAA#BC09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF3CAA#HC09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG2DFB#UA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GBF3CFP#UA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GBG2DFP#UA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GFF3CFP#UA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GFG2DFP#UA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGF3CFB#UA09612-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGG2DFB#UA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GJF3CFA#UA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GJG2DFA#UA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF3CFB#UA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF3CFA#UA09612-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG2DFA#UA012816-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GMG3CFB#UA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMG2DFB#UA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GMG3CFA#UA012816-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMG2DFA#UA012816-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GPG3CFB#UA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPG2DFB#UA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GPG3CFA#UA012816-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPG2DFA#UA012816-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GBF2DFP#UA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GBG3CFP#UA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GFF2DFP#UA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GFG3CFP#UA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGF2DFB#UA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGG3CFB#UA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GJF2DFA#UA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GJG3CFA#UA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF2DFB#UA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG3CFB#UA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLF2DFA#UA09612-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLG3CFA#UA012816-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GSN2DFB#UA076848-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GSL2DFB#UA051248-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GSK2DFB#UA038432-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GSJ2DFB#UA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GSN3CFB#UA076848-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GSL3CFB#UA051248-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GSK3CFB#UA038432-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GSJ3CFB#UA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GPL2DFB#UA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GMJ2DFB#UA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GMH2DFB#UA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GMJ3CFB#UA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMH3CFB#UA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GBG2DNP#UA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GAG2DSP#UA012816-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GPN2DFB#UA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GLN2DFB#UA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GGN2DFB#UA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GMJ2DFA#UA025624-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GLJ2DFB#UA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GJJ2DFA#UA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GGJ2DFB#UA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GBJ2DFP#UA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GMN2DFA#UA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GMN2DFB#UA076848-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GJN2DFA#UA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GPN2DFA#UA076848-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GLN2DFA#UA076848-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GFN2DFP#UA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GBH2DFP#UA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GGH2DFB#UA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGK2DFB#UA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGL2DFB#UA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GLK2DFA#UA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL2DFA#UA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH2DFB#UA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GMH2DFA#UA019220-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GML2DFB#UA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GPH2DFA#UA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GPJ2DFA#UA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GPK2DFA#UA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GPL2DFA#UA051248-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GFN3CFP#UA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GAG3CSP#UA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GBJ3CFP#UA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GBH3CFP#UA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GBG3CNP#UA012816-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GGH3CFB#UA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGJ3CFB#UA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGN3CFB#UA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGL3CFB#UA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GJJ3CFA#UA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GJN3CFA#UA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GJK3CFA#UA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GJL3CFA#UA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN3CFA#UA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK3CFA#UA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL3CFA#UA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ3CFB#UA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLN3CFB#UA076848-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH3CFB#UA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK3CFB#UA038432-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL3CFB#UA051248-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GMJ3CFA#UA025624-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMN3CFA#UA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMH3CFA#UA019220-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMK3CFA#UA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GML3CFA#UA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMN3CFB#UA076848-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GMK3CFB#UA038432-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GML3CFB#UA051248-40 to 105°C12-bit x 17-ch8-bit x 2-ch
R7F100GPN3CFA#UA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPH3CFA#UA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPJ3CFA#UA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPK3CFA#UA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPL3CFA#UA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPN3CFB#UA076848-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPH3CFB#UA019220-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPJ3CFB#UA025624-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPK3CFB#UA038432-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GPL3CFB#UA051248-40 to 105°C12-bit x 20-ch8-bit x 2-ch
R7F100GAJ2DSP#UA025624-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GAF2DSP#UA09612-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GAH2DSP#UA019220-40 to 85°C12-bit x 8-ch8-bit x 2-ch
R7F100GAJ3CSP#UA025624-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GAF3CSP#UA09612-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GAH3CSP#UA019220-40 to 105°C12-bit x 8-ch8-bit x 2-ch
R7F100GBF2DNP#UA09612-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GBF3CNP#UA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GBH2DNP#UA019220-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GBH3CNP#UA019220-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GBJ2DNP#UA025624-40 to 85°C12-bit x 26-ch8-bit x 2-ch
R7F100GBJ3CNP#UA025624-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GEF2DNP#UA09612-40 to 85°C12-bit x 9-ch8-bit x 2-ch
R7F100GEF3CNP#UA09612-40 to 105°C12-bit x 9-ch8-bit x 2-ch
R7F100GEG2DNP#UA012816-40 to 85°C12-bit x 9-ch8-bit x 2-ch
R7F100GEG3CNP#UA012816-40 to 105°C12-bit x 9-ch8-bit x 2-ch
R7F100GEH2DNP#UA019220-40 to 85°C12-bit x 9-ch8-bit x 2-ch
R7F100GEH3CNP#UA019220-40 to 105°C12-bit x 9-ch8-bit x 2-ch
R7F100GEJ2DNP#UA025624-40 to 85°C12-bit x 9-ch8-bit x 2-ch
R7F100GEJ3CNP#UA025624-40 to 105°C12-bit x 9-ch8-bit x 2-ch
R7F100GFJ2DFP#UA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GFJ3CFP#UA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGK3CFB#UA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGF2DNP#UA09612-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGF3CNP#UA09612-40 to 105°C12-bit x 26-ch8-bit x 2-ch
R7F100GGG2DNP#UA012816-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGG3CNP#UA012816-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGH2DNP#UA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGH3CNP#UA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGJ2DNP#UA025624-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGJ3CNP#UA025624-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGK2DNP#UA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGK3CNP#UA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGL2DNP#UA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGL3CNP#UA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GGN2DNP#UA076848-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GGN3CNP#UA076848-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GJK2DFA#UA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GJL2DFA#UA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH2DFA#UA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLH3CFA#UA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ2DFA#UA025624-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLJ3CFA#UA025624-40 to 105°C12-bit x 12-ch8-bit x 2-ch
R7F100GLK2DFB#UA038432-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GLL2DFB#UA051248-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GMK2DFA#UA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GML2DFA#UA051248-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GMK2DFB#UA038432-40 to 85°C12-bit x 17-ch8-bit x 2-ch
R7F100GPH2DFB#UA019220-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GPJ2DFB#UA025624-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GFK3CFP#UA038432-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GFL2DFP#UA051248-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GFL3CFP#UA051248-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GPK2DFB#UA038432-40 to 85°C12-bit x 20-ch8-bit x 2-ch
R7F100GFH2DFP#UA019220-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GFH3CFP#UA019220-40 to 105°C12-bit x 10-ch8-bit x 2-ch
R7F100GFK2DFP#UA038432-40 to 85°C12-bit x 10-ch8-bit x 2-ch
R7F100GJH2DFA#UA019220-40 to 85°C12-bit x 12-ch8-bit x 2-ch
R7F100GJH3CFA#UA019220-40 to 105°C12-bit x 12-ch8-bit x 2-ch


推薦資訊

  • Solitron SD11720 N溝道功率MOSFET
    Solitron SD11720 N溝道功率MOSFET 2024-07-22 10:19:25

    SD11720是一款SiC N溝道功率MOSFET，由Solitron Devices, Inc.推出，專為高效率和可靠性的功率電子應用設計。采用先進的碳化硅技術，提供卓越的電氣和熱性能，適用于工業和能源應用。主要特點包括58A漏極電流、50mΩ導通狀態電阻和TO-247-3塑料封裝。優勢包括低導通電阻的高阻斷電壓、低電容的高速開關、高工作結溫能力（高達175°C）和較強的內置體二極管性能。應用領域包括太陽能逆變器、不間斷電源、電機驅動器、高電壓直流/直流轉換器和開關模式電源。SD11720的高性能和廣泛應用使其成為功率電子領域的關鍵組件，滿足現代系統對高效率和高可靠性的要求。

  • ADI晶圓AD8065
    ADI晶圓AD8065 2022-09-26 16:55:12

    AD8065?/AD8066 FastFET功率放大器均是電壓反饋功率放大器FET輸入，性能優質，方便使用。AD8065是單路功率放大器，AD8066是雙路功率放大器。ADI公司的專用XFCB制造工藝，工作噪音超低(7.0nV/√Hz和0.6fA/√Hz），輸入阻抗非常高。

在線留言

在線留言

 吉木乃县| 云梦县| 濮阳市| 沂水县| 鄯善县| 墨脱县| 洛隆县| 册亨县| 兴业县| 饶平县| 蛟河市| 丽江市| 登封市| 建阳市| 平利县| 襄樊市| 辉南县| 茌平县| 黔江区| 绿春县| 漠河县| 吉水县| 洪湖市| 紫阳县| 马关县| 贞丰县| 盐源县| 新津县| 孝感市| 奉新县| 穆棱市| 深泽县| 绿春县| 山东省| 莲花县| 阿合奇县| 阳春市| 青冈县| 祁东县| 长阳| 鲁山县|
